Serialized full-scenario positioning components
• Multi-frequency signal generation based on GNSS-based 1PPS
• Multi-sensor simultaneous acquisition
• Multi-device time synchronization
High synchronization accuracy and small synchronization delay
Input and output pulse parameters are adjustable through the serial port
Supports eight-channel signal synchronization at the same time
Supports both internal and external pulse triggering, and automatically switches to internal pulse triggering when there is no external pulse.
Low frequency error, the error is no more than 10PPM
Synchronization accuracy is less than 5us
| parameter name | Parameter value | describe |
| Input pulse characteristics | Input pulse characteristics | 0~10hz |
| Input level type | TTL level (0-3.3V) | |
| Input level type | TTL level (0-3.3V) | |
| Output pulse characteristics | Output pulse range | 1~4000hz |
| Output level type | TTL level (0-3.3V) | |
| Level hold time | >250us | |
| Output pulse maximum current | <5mA | |
| Synchronization features | Input-output synchronization accuracy | <5us |
| Output - Output synchronization accuracy | <5us | |
| Internal frequency stability | ±10ppm | |
| Environmental characteristics | range of working temperature | -40℃ ~+85℃ |
| Storage temperature range | -40℃ ~+85℃ | |
| Humidity range | 0~95% | |
| Anti-vibration, anti-shock | IEC 60068-2-6:2007 IEC 60068-2-27:2008 |
|
| Waterproof and dustproof | IP63 | |
| Power supply characteristics | Supply voltage | DC5V±5% |
| Machine power consumption | <1W | |
| Measured state average current | < 80mA (5V power supply) |
